SureCall Force 5 Cellular Amplifier with Sentry

https://www.expertmobile.ca/web/image/product.template/4812/image_1920?unique=012ee15
(0 review)

The Most Powerful Cell Signal Booster for the Large Offices and Commercial Buildings. Voice, Text & 4G LTE Cell Phone Signal Booster for Large Buildings 25,000+ sq ft

3,750.00 3750.0 CAD 3,750.00

3,750.00

    This combination does not exist.

    Product Description

    Commercial Integrator BEST and CE Pro BEST award winner, Force5 2.0™ is the next evolution in cellular signal boosting technology and the #1 DAS alternative.

    Equipped with SureCall’s built-in Sentry remote monitoring hardware, Force5 2.0 is the first cell phone signal booster with integrated remote access to adjust and optimize booster performance from off-site via mobile app.

    • Boosts voice, text and 5G/4G LTE signals for all North American cell carriers
    • Increases signal strength 25,000 sq ft in typical conditions and up to 100,000 sq ft in ideal conditions*
    • Reduces dropped & missed calls and improves data performance
    • SureIQ™ Technology balances incoming signals, preventing shutdown and maximizing performance in strong signal environments
    • +17 dBm downlink power provides expansive indoor coverage
    • Multiple kitting options offer the flexibility to customize installation in any building or floor plan
    • 5G compatible - Force5 2.0 supports all 5G & 4G LTE devices
    • Industry best 3-year warranty and lifetime US-based tech support, 5-year extended warranty available

    *Coverage up to 100,000 sq ft in ideal conditions with outdoor signal strength -50dB or stronger and open indoor spaces. Additional antennas may be required.

    User Guide

    Data Sheet





    About Sentry Remote Monitoring

    Force5 2.0's integrated Sentry hardware offers seamless off-site adjustments to maximize performance at every location. A must-have for building owners, managers and installers, Sentry provides fast adjustments via remote access when continuous up-time is mission critical.

    • Access via Android® app, iPhone® app or Sentry web portal
    • Quickly pinpoint malfunctions due to unforeseen changes such as newly installed cellular towers or repeater systems
    • Immediately notifies you about booster changes and over-powering
    • Remotely monitor and adjust booster performance, including uplink, downlink or band
    • Optimize installation by monitoring and identifying the strongest signal strength available

    Technical Information

    Uplink Frequency Range (MHz):698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included)
    Downlink Frequency Range (MHz):728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included)
    Supported Standards:CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards
    Input/Output Impedance:50 Ohm
    Maximum Gain:72 dB
    Noise Figure:5 dB
    VSWR:≤2.0
    AC Power Transmitter:Input AC 110 V, 60 Hz / Output DC 15-20 V
    Maximum Output Power:1 Watt EIRP
    Cable:SC-400
    RF Connectors:N Female (both ends)
    Operating Temperature:-4°F to +158°F
    Power Consumption:<65W
    Dimensions:14.5" x 11" x 3.5"
    Weight:23.5 lbs


    Booster Kit Includes

    • (1) Force5 2.0 booster with built-in Sentry monitoring system
    • (1) Power Supply
    • (1) USB cable to set up Sentry software

    Specifications

    Booster Brand SureCall
